The Gas(oil) Fired Vertical Steam Boiler shell-type fire tube structure is adopted, and the flame is burned downward to enhance the heat transfer effect, thereby reducing the convective heating area; the flow resistance of the flue gas is small, the running power consumption is low, and the operation cost is saved.
InquiryThe condensing recovery device is used to make full use of each minute of heat, and the thermal efficiency can reach 96% or more, reducing the fuel input cost.
The use of automatic welding equipment, welding more accurate; flaw detection before leaving the factory, to achieve a 100% pass rate and then confirm the factory.
The system monitors the water quality in real-time, automatically discharges the sewage, reduces the amount of fouling inside the Gas(oil) Fired Vertical Steam Boiler, and ensures steam quality.
Add a fifth water level test to detect whether the Gas(oil) Fired Vertical Steam Boiler is short of water and timely stop the shutdown and alarm to ensure the safety of the boiler.
Gas(oil) Fired Vertical Steam Boiler Rated thermal power: 0.5-1.0t/h
Gas(oil) Fired Vertical Steam Boiler Rated thermal efficiency: 95-96%
Gas(oil) Fired Vertical Steam Boiler Pressure: ≤0.8MPa
Gas(oil) Fired Vertical Steam Boiler Available fuel: natural gas, liquefied petroleum gas, etc.
Multiple security protection
More than ten safety protection systems such as water shortage protection, power protection, pressure controller, and scale monitoring are adopted. Once a fault occurs, the alarm system is immediately activated to maintain the overall safety of the Gas(oil) Fired Vertical Steam Boiler.
An Integrated solution of waste heat is added. The condensing device is installed at the tail of the flue pipes. After the high-temperature flue gas passes, the latent heat is released. The exhaust gas temperature can be lowered to 95 °C, the thermal efficiency is as high as 96%.
