This Gas(oil) Fired Split Steam Boiler is designed with a classic shell type, full-wet back, down-flow, and three-pass design structure. The fuel is fully burned in the large-capacity combustion chamber, and the combustion heat load is low, which can greatly reduce the emission of harmful substances such as CO and NOx.
InquiryThrough the heat recovery device, the flue gas waste heat is reused, the exhaust gas temperature is as low as 95 ° C, the thermal efficiency can reach 97-100%, and the Gas(oil) Fired Split Steam Boiler efficiency is maximized.
The Gas(oil) Fired Split Steam Boiler is equipped with a PLC intelligent control system, which can flexibly adjust the operating state of the boiler according to actual needs, realizing digital setting and automatic adjustment.
The Gas(oil) Fired Split Steam Boiler adopts an integrated design structure, and the user only needs to complete the construction and connection of water, smoke, and gas pipelines.
More than 95% of the main welds of the boiler are automatically welded and molded at one time; the furnace body is fully tested for flaw detection, and the pass rate is over 99%.
Gas(oil) Fired Split Steam Boiler Rated thermal power: 1-20t/h
Gas(oil) Fired Split Steam Boiler Rated thermal efficiency: 97-100%
Gas(oil) Fired Split Steam Boiler Pressure: ≤3.82MPa
Gas(oil) Fired Split Steam Boiler Available fuel: diesel, heavy oil, natural gas, city gas, etc.
Industrial PLC intelligent control system
The control device is combined with the programmable controller and the mechatronics control scheme to realize the automatic operation of the Gas(oil) Fired Split Steam Boiler, and the operation is simpler.
Using more than 95% of the automatic welding equipment ensures that the welding is formed once; the whole boiler is flaw-detected, and the pass rate is as high as 99%, providing users with excellent quality boilers.
